Specification
- Bare Copper
- Comes in 100m Drum
Code | Cores/Pairs | Strand No / Size | Nominal Area mm² | Insulation Thickness | Electrical Resistance @ 20°C (ohm/km) | Nominal OD | |
---|---|---|---|---|---|---|---|
LFD212702 | 2 | 127/.2 | 4 | 1 | 4.63 | 4.7 x 9.5 | |
LFD219202 | 2 | 192/.2 | 6 | 1 | 3.1 | 5.5 x 11.5 | |
LFD230025 | 2 | 30.25 | 1.5 | 1.1 | 13.7 | 4.0 x 8.3 | |
LFD23202 | 2 | 32/.2 | 1 | 0.6 | 26.7 | 2.6 x 5.7 | |
LFD232202 | 2 | 322/.2 | 10 | 0.66 | 1.83 | 6.0 x 12.5 |
